Premium mahogany construction and an ultra-musical active/passive preamp design deliver the flexibility and sheer tonal quality you need to sculpt the perfect sound.

• Sculpted, Solid Mahogany Body
• 5-Piece Maple/Mahogany Neck
• 2 YGD-designed H5 Alnico Humbucking Pickups
• Active Electronics w/Passive Switchability

The TRBX500 series features controls for master volume, balance, 3-band EQ and an active/passive switch for maximum flexibility

YGD-designed H5 pickups are defined by a clean, open tone perfectly matched with the flexibility of the active/passive preamp design. Its quad-polepiece design and Alnico magnets give them the power to drive the active circuit, and the sensitivity and subtlety to capture every nuance in passive mode.

Featuring an audiophile-grade active/passive circuit for fine tonal control and extreme flexibility, the advanced design offers a level-matched output whether in passive or active and tone-switching circuitry mode, which seamlessly moves from treble control to master passive tone. High-quality, gold-plated parts are used for key signal chain contacts, providing increased conductivity and reliability, and an LED installed on the back panel gives instant indication of a low battery to prevent sudden power loss during performances.

FEATURES

• Construction: Bolt-on
• Scale Length: 34" (863.6 mm)
• Body Materials: Mahogany
• Body Finish: Satin Polyurethane
• Neck Materials: Maple/Mahogany 5-Piece
• Neck Finish: Satin Polyurethane
• Fingerboard Materials: Rosewood
• Fingerboard Radius: 10'' (250 mm)
• Fret Wire: Medium
• Number of Frets: 24
• Nut Materials: Urea
• Width @ 0 Fret / 12th Fret: 38.0 / 56.4 mm
• Thickness @ 1st Fret / 12th Fret: 19.5 / 21.5 mm
• Neck Pickup: Double Coil / Alnico V
• Middle Pickup: -
• Bridge Pickup: Double Coil / Alnico V
• Controls: Master Volume, Pickup Balancer, 3-Band EQ(Bass, Middle, Treble), Active/Pssive Switch.
• Pickup Switch: -
• Bridge: Die-cast
• String Spacing: 19mm
• Tailpiece: -
• Tuning Machines: Covered / Die-cast
• Pickguard: -
